Sony DCR-PC101E - Node Unique ID No. Input; Input of Company ID; Input of Serial no

DCR-PC101/PC101E
5-48
D
1
(decimal) D
2
(decimal) H
1
(hexadecimal)
(Service model code)
00001 to 65535 D
1
00
65536 to 131071 D
1
– 65536 00
131072 to196607 D
1
– 131072 00
196608 to 262143 D
1
– 196608 00
Table 5-3-2
3. Node Unique ID No. Input
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Perform “3-2. Input of Serial No.” if the data on page 8
has been cleared and the node unique ID No. is not found.
3-1. Input of Company ID
Write the company ID to the EEPROM (nonvolatile memory).
Page 8
Address 8C, 8D, 8E, 8F, 90
Input method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 8, and enter the following data.
Note 2: Each time the data is set, press the PAUSE button on the
adjusting remote commander.
Address Data
8C 08
8D 00
8E 46
8F 01
90 02
3) Select page: 0, address: 01, and set data: 00.
3-2. Input of Serial No.
Write the serial No. and model code to the EEPROM (nonvolatile
memory).
In writing the serial No., a decimal number should be converted
into a hexadecimal number.
1) Select page: 0, address: 01, and set data: 01.
2) Read the serial No. from the model name label, and it is as-
sumed to be D
1
.
Example: If serial No. is “77881”,
D
1
= 77881
3) From Table 5-3-2, obtain D
2
and H
1
that correspond to D
1
.
Example: If D
1
= 77881,
D
2
= D
1
– 65536 = 12345
H1 = 00
Page 8
Address 91, 92, 93
4) Enter H
1
to address: 91 on page: 8.
Example: If H
1
= 00,
select page: 8, address: 91, and set data: 00, then press the
PAUSE button.
5) From Table 5-3-3, obtain the maximum decimal number less
than D
2
, and it is assumed to be D
3
.
Example: If D
2
= 12345.
D
3
= 12288
6) From Table 5-3-3, obtain a hexadecimal number that corre-
sponds to D
3
, and it is assumed to be H
3
.
Example: If D
3
= 12288,
H
3
= 3000
7) Caluculate D
4
using following equations (decimal
caluculation). (0
D
4
225)
D
4
= D
2
– D
3
Example: If D
2
= 12345 and D
3
= 12288,
D
4
= 12345 – 12288 = 57
8) Convert D
4
into a hexadecimal number to obtain H
4
. (See Table
5-4-1 “Hexadecimal - decimal conversion table” in 5-4. Ser-
vice Mode)
Example: If D
4
= 57,
H
4
= 39
9) Enter higher two digits of H
3
to address: 92 on page: 8.
Example: If H
3
= 3000,
select page: 8, address: 92, and set data: 30, then press the
PAUSE button.
10) Enter H
4
to address: 93 on page: 8.
Example: If H
4
= 39,
select page: 8, address: 93, and set data: 39, then press the
PAUSE button.
11) Select page: 0, address: 01, and set data: 00.
