Sony DCR-PC101E - Initialization of A, D Page Data; Modification of A, D Page Data

DCR-PC101/PC101E
5-9
2. Modification of A, D Page Data
If the A, D page data has been initialized, change the data of
the“Fixed data-2” address shown in the following table by manual
input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note 1: If copy the data built in the different model, the
camcorder may not operate.
3) When changing the data, press the PAUSE button of the ad-
justment remote commander each time when setting new data
to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification A, D page data:
Order Page Address Data Procedure
1 2 00 29
2 2 01 29 Press PAUSE button.
Note 2: If the following symptoms occur after completing of
the“Modification A, D page data”, check that the data of
the “Fixed data-2” addresses of A, D page are same as
those of the same model of the same destination.
1) “E: 20: 00” of self-diagnosis code on LCD screen is
flashing.
2) The power is shut off so that unit cannot operate.
1-2-1. Initialization of A, D Page Data
Note: Check that the data of page: 0, address: 10 is “00”.
1. Initializing of A, D Page Data
Note 1: If the A, D page data has been initialized, the following
adjustments need to be performed again.
1) Modification of A, D page data
2) Touch panel adjustment
Note 2: Check that the voltage of power supply is 6.0 ± 0.1Vdc.
Note 3: NTSC model: DCR-PC101
PAL model: DCR-PC101E
Adjustment Page A
Adjustment Address 10 to FF
Adjustment Page D
Adjustment Address 10 to 67
A page initializing method:
Order Page Address Data Procedure
1 0 01 01
2 0 10 00
37 03
Set the following data
06: NTSC model
86: PAL model
4 7 00 20
5 7 01 20 Press PAUSE button.
67 02
Check the data changes to
“01”.
7 2 00 29
8 2 01 29 Press PAUSE button.
9
Perform “Modification of A,
D Page Data”
D page initializing method:
Order Page Address Data Procedure
1 0 01 01
2 0 10 00
37 03
Set the following data
06: NTSC model
86: PAL model
4 7 00 22
5 7 01 22 Press PAUSE button.
67 02
Check the data changes to
“01”.
7 2 00 29
8 2 01 29 Press PAUSE button.
9
Perform “Modification of A,
D Page Data”
