DCR-PC101/PC101E
5-12
4. C Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, C Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, C Page Data”)
Address
Initial value
Remark
NTSC PAL
10 EE EE
11 00 00
12 00 00
Switching position adj.
13 00 00
14, 15 Fixed data-1 (Initialized data)
16 E0 E0 CAP FG duty adj.
17 Fixed data-1 (Initialized data)
18 2A 2A
APC & AEQ adj.
19 2A 2A
1A Fixed data-1 (Initialized data)
1B 32 32
APC & AEQ adj.
1C 32 32
1D Fixed data-1 (Initialized data)
1E 25 25 AGC center level adj.
1F 3E 3E
PLL f
0
& LPF f
0
adj.
20 3E 3E
21 DC DC APC & AEQ adj.
22 99 99 PLL f
0
& LPF f
0
adj.
23, 24 Fixed data-1 (Initialized data)
25 88 88 S VIDEO OUT Y level adj.
26 E3 E3
S VIDEO OUT chroma level adj.
27 A1 A1
28 04 04 Chroma BPF f
0
adj.
29 20 20 PLL f
0
& LPF f
0
adj.
2A, 2B Fixed data-1 (Initialized data)
2C 03 03 APC & AEQ adj.
2D to 4E Fixed data-1 (Initialized data)
4F 6F 6F
Back light adj. (EVF)
50 CF CF
51 46 9B
VCO adj. (EVF)
52 63 7D
53 Fixed data-2
54 8A 88 RGB AMP adj. (EVF)
55 Fixed data-1 (Initialized data)
56 8D 8D
White balance adj. (EVF)
57 73 73
58 35 35 Contrast adj. (EVF)
59 Fixed data-1 (Initialized data)
5A
5B
5C
5D
Fixed data-2
5E
5F
3. 8 Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the 8, C Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of 8, C Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to 18 Fixed data-1 (Initialized data)
19 Fixed data-2
1A to 2E Fixed data-1 (Initialized data)
2F Fixed data-2
30 to 3A Fixed data-1 (Initialized data)
3B Fixed data-2
3C to 49 Fixed data-1 (Initialized data)
4A Fixed data-2
4B to 51 Fixed data-1 (Initialized data)
52 Fixed data-2
53 to 59 Fixed data-1 (Initialized data)
5A Fixed data-2
5B to 61 Fixed data-1 (Initialized data)
62 Fixed data-2
63 to 79 Fixed data-1 (Initialized data)
7A
7B
7C
7D
7E Fixed data-2
7F
80
81
82
83
84 to 89 Fixed data-1 (Initialized data)
8A Fixed data-2
8B Fixed data-1 (Initialized data)
8C 08 08
8D 00 00
8E 46 46
8F 01 01
90 02 02
Node unique ID No. input
91 00 00
92 00 00
93 00 00
94 to A3 Fixed data-1 (Initialized data)
