Sony DCR-PC101E - Board; Position to Install FP-470 Board When Installing LCD Hinge Assembly, Blind Plate Assembly; Installation of FP-470 Flexible Board; Harness (PB-051)

2-12
DCR-PC101/PC101E
[INSTALLATION OF FP-470 FLEXIBLE
BOARD, HARNESS (PB-051)]
[POSITION OF CONNECTOR RETAINER
SHEET]
[POSITION TO INSTALL FP-470 BOARD
WHEN INSTALLING LCD HINGE
ASSEMBLY, BLIND PLATE ASSEMBLY]
[NOTE FOR INSTALLATION OF LCD
HINGE BLOCK]
Blind plate assembly
FP-470 flexible board
Harness (PB-051)
LCD hinge assembly
Blind plate assembly
Hook this portion
on the cabinet (R)
to install the blind plate
assembly.
Cabinet (R)
LCD hinge block
FP-470 flexible board
FP-470 flexible board
Harness (PB-051)
Harness (PB-051)
BJ-003 board
Connector retainer
sheet
Hinge block assembly
FP-470
flexible board
