DCR-PC101/PC101E
5-67
Address
B0
B1
B2
B4
B5
B6
B8
B9
BA
BC
BD
BE
C0
C1
C2
C4
C5
C6
Self-diagnosis code
“Repaired by” code (Occurred 1st time) *1
“Block function” code (Occurred 1st time)
“Detailed” code (Occurred 1st time)
“Repaired by” code (Occurred 2nd time) *1
“Block function” code (Occurred 2nd time)
“Detailed” code (Occurred 2nd time)
“Repaired by” code (Occurred 3rd time) *1
“Block function” code (Occurred 3rd time)
“Detailed” code (Occurred 3rd time)
“Repaired by” code (Occurred 4th time) *1
“Block function” code (Occurred 4th time)
“Detailed” code (Occurred 4th time)
“Repaired by” code (Occurred 5th time) *1
“Block function” code (Occurred 5th time)
“Detailed” code (Occurred 5th time)
“Repaired by” code (Occurred the last time) *1
“Block function” code (Occurred the last time)
“Detailed” code (Occurred the last time)
9. Record of Self-diagnosis check
Page 7 Address B0 to C6
Note 1: This data will not be erased (reset) when the lithium 3 V
power supply (NS-014 board BT001) is removed.
Note 2: Check that the data of page: 0, address 10 is “00”.
*1 : “01” t “C”, “03” t “E”
Using method:
1) The past self-diagnosis codes are displayed at page: 7, ad-
dress: BC to C6. Refer to “1-2. SELF-DIAGNOSIS FUNC-
TION” of “1. SERVICE NOTE” for detail of the self-diagno-
sis code.
