Sony DCR-PC101E User Manual

DCR-PC101/PC101E
5-16
Address
Initial value
Remark
NTSC PAL
F1
F2 Fixed data-2
F3
F4 Fixed data-1 (Initialized data)
F5 Fixed data-2
F6 Fixed data-1 (Initialized data)
F7 Fixed data-2
F8 Fixed data-1 (Initialized data)
F9 Fixed data-2
FA to FF Fixed data-1 (Initialized data)
4. F Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the E, F, 1E, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of E, F, 1E, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
10 40 40 66MHz/54MHz origin oscillation adj.
11, 12 Fixed data-1 (Initialized data)
13 28 28
14 70 70
15 28 28
16 40 40
Hall adj.
17 80 80
18 D8 D8
19 A0 A0 MAX GAIN adj.
1A 80 80
AWB & LV standard data input
1B 7A 7A
1C 80 80
1D 80 80
1E 80 80
1F 80 80 F No. & ND light quality standard
20 80 80 data input
21 80 80
22 80 80
23 80 80
24 to 2F Fixed data-1 (Initialized data)
30 4D 4D
31 3E 3E
32 64 64
AWB & LV standard data input
33 59 59
34 96 96
Auto white balance adj.
35 7A 7A
36 Fixed data-1 (Initialized data)
37 2C 2C Color reproduction adj.
38 Fixed data-1 (Initialized data)
39 26 26 Color reproduction adj.
3A to 3F Fixed data-1 (Initialized data)
40 01 01
Color reproduction adj.
41 E8 E8
42, 43 Fixed data-1 (Initialized data)
44 2C 2C
45 10 10
46 5A 5A
Auto white balance adj.
47 50 50
48 3F 3F
49 10 10
4A 39 39
4B C2 C2
Flange back adj.
4C 1E 1E
4D 2E 2E
E Page table
