Sony DCR-PC101E - Initialization of 8, C Page Data

DCR-PC101/PC101E
5-11
1-2-2. Initialization of 8, C Page Data
Note: Check that the data of page: 0, address: 10 is “00”.
1. Initializing of 8, C Page Data
Note1: If “Initialization of Pages 8, C” is executed, all data on
pages 8, C are initialized. (Only an individual page can-
not be initialized)
Note 2: If the 8, C page data has been initialized, the following
adjustments need to be performed again.
1) Modification of 8, C page data
2) Color electronic viewfinder system adjustments
3) LCD system adjustments
4) Node unique ID No. input
5) Servo, RF system adjustments
6) Video system adjustments
Note 3: Check that the voltage of power supply is 6.0 ± 0.1Vdc.
Adjustment Page 8
Adjustment Address 00 to A3
Adjustment Page C
Adjustment Address 10 to FF
Initializing method:
Order Page Address Data Procedure
1 0 01 01
2 0 10 00
33 81
Check the data changes to
“00”.
4 3 80 0C Press PAUSE button.
53 80
Check the data changes to
“1C”.
6
Perform “Modification of 8,
C Page Data”
2. Modification of 8, C Page Data
If the 8, C page data has been initialized, change the data of the
“Fixed data-2” address shown in the following table by manual
input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the
camcorder may not operate.
3) When changing the data, press the PAUSE button of the ad-
justment remote commander each time when setting new data
to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification 8, C page data:
Order Page Address Data Procedure
1 2 00 29
2 2 01 29 Press PAUSE button.
