4-97
DCR-PC101/PC101E
COVER
COVER
CF-089 BOARD SIDE A CF-089 BOARD SIDE B
CF-089 BOARD SIDE A CF-089 BOARD SIDE B
CF-089 BOARD
IC305 5 REC
400 mVp-p
2
IC305 qa REC
400 mVp-p
44 µsec (PC101)
54 µsec (PC101E)
44 µsec (PC101)
54 µsec (PC101E)
1
CF-089
4-4. WAVEFORMS
