NS-014 (REMOTE COMMANDER RECEIVER)
For Printed Wiring Board.
• :Uses unleaded solder.
• NS-014 board is six-layer print board. However, the patterns of
layers 2 to 5 have not been included in the diagram.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or eqivalent type.
D704
(REC)
D701
IC701
D702
D703
BT001
R704
NS-014 BOARD(SIDE A)
BT001
LITHIUM BATTERY
(SECONDARY)
KA
14
A
K
23
D702, 703
(NIGHT SHOT)
1-684-897-
05
11
1
10
NS-014 BOARD(SIDE B)
1-684-897-
05
11
10
1
• There are a few cases that the part isn't mounted in this model
is printed on this diagram.
