DCR-PC101/PC101E
5-29
12. AWB & LV Standard Data Input
RadarW
RadarW
RadarW
Adjust the white balance reference at 3200K, and adjust the nor-
mal coefficient of the light value.
Subject Clear chart
(Color reproduction adjustment
frame)
Measurement Point Displayed data of page: 1 (Note 5)
Measuring Instrument Adjusting remote commander
Adjustment Page F
Adjustment Address 1A, 1B, 30 to 33
Specified Value 0FF0 to 1010
Note 1: Perform “Color Reproduction Adjustment” before this
adjustment.
Note 2: “AWB & LV Standard Data Input” is available only once
after the power is turned on. Turn the power off, then on
again if the adjustment is retried.
Note 3: Check that the data of page: 0, address: 10 is “00”.
Note 4: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 5: The right four digits of the page: 1 displayed data of the
adjusting remote commander.
1 : XX : XX
Displayed data
Switch setting
1) POWER ...................................................................CAMERA
2) NIGHT SHOT.................................................................. OFF
3) DIGITAL ZOOM (Menu setting).................................... OFF
4) STEADY SHOT (Menu setting) ..................................... OFF
Adjusting method:
Order Page Address Data Procedure
1 0 01 01
2 6 16 02
3 Wait for 2 seconds.
4 6 01 11 Press PAUSE button.
5 6 01 0D Press PAUSE button. (Note 6)
66 02
Check the data changes to
“01”.
70 031E
81
Check that the displayed data
(Note 5) satisfied the
specified value.
Note 6: The adjustment data will be automatically input to page:
F, address: 1A, 1B, 30 to 33.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
2 6 16 00
3 0 03 00
4 0 01 00
To Next Page
