DCR-PC101/PC101E
5-10
4. D Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the A, D Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of A, D Page Data”)
Address
Initial value
Remark
NTSC PAL
10 00 00 Test mode
11 Fixed data-1 (Initialized data)
12 Fixed data-2
13 to 15 Fixed data-1 (Initialized data)
16 Fixed data-2
17 to 21 Fixed data-1 (Initialized data)
22
23
24 Fixed data-2
25
26
27 to 29 Fixed data-1 (Initialized data)
2A
2B
Fixed data-2
2C to 36 Fixed data-1 (Initialized data)
37 Fixed data-2
38 Fixed data-1 (Initialized data)
39
3A
Fixed data-2
3B to 53 Fixed data-1 (Initialized data)
54
55
Fixed data-2
56 to 5E Fixed data-1 (Initialized data)
5F Fixed data-2
60 to 67 Fixed data-1 (Initialized data)
3. A Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the A, D Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of A, D Page Data”)
Address
Initial value
Remark
NTSC PAL
10 to 17 Fixed data-1 (Initialized data)
18 Fixed data-2
19 to 2E Fixed data-1 (Initialized data)
2F Fixed data-2
30 to 51 Fixed data-1 (Initialized data)
52 Fixed data-2
53 Fixed data-1 (Initialized data)
54 Fixed data-2
55 Fixed data-1 (Initialized data)
56 Fixed data-2
57 to 8F Fixed data-1 (Initialized data)
90 D0 D0
Touch panel adj.
91 1E 1E
92 D0 C3
93 15 1E
94 to A0 Fixed data-1 (Initialized data)
A1 Fixed data-2
A2 to CF Fixed data-1 (Initialized data)
D0
D1
Fixed data-2
D2 to FF Fixed data-1 (Initialized data)
