Sony DCR-PC101E - Page 70

DCR-PC101/PC101E
5-6
Fig. 5-1-3
CPC-6 terminal board jig
(J-6082-371-A)
CPC-6 flexible jig (J-6082-370-B)
Vectorscope color monitor
Video (Yellow)
LANC jack
VC-284 board
NS-014 board
FP-470
FLEXIBLE
CN1010
CN1005
CN1003
CN804 CN802
CN801
CN007
CN803
CN1006
CN404CN101
CN104
CN1001
ME-020
board
CF-089
board
BJ-003
board
INVERTER
TRANS-
FORMER
UNIT
PD-166
board
Audio/Video jack
DV jack
USB jack
DC IN
jack
Audio L (White)
Audio R (Red)
Adjustment remote commander
Terminated at 75 Ω
Need not connected
Need not connected
Must be connected.
Must be connected when performing
the LCD system adjustments.
Must be connected when
performing the video or
EVF system adjustments.
cpc-jig for LCD panel
(J-6082-529-A)
61
AC power adaptor
(8.4 Vdc)
AC-L10, AC-VQ800 etc.
CN402
CN005
CN001
CN002
CN1009
