DCR-PC101/PC101E
5-18
5. 1E Page table
Note 1: If reading/writing data on pages 1E, set data: 01 to page:
0, address: 10, and then select pages E. By this data set-
ting, the pages 1E can be selected.
After the data reading/writing finished, return the data
on page: 0, address: 10 to “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the E, F, 1E, 1F Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of E, F, 1E, 1F Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to 0F Fixed data-1 (Initialized data)
10 Fixed data-2
11 to 1F Fixed data-1 (Initialized data)
20 00 00
21 00 00
22 00 00
23 00 00
24 00 00
25 00 00
26 00 00
27 00 00 CCD black defect adj.
28 00 00
29 00 00
2A 00 00
2B 00 00
2C 00 00
2D 00 00
2E 00 00
2F 00 00
30 to 71 Fixed data-1 (Initialized data)
72
73
Fixed data-2
74 to 81 Fixed data-1 (Initialized data)
82 Fixed data-2
83 to 85 Fixed data-1 (Initialized data)
86 Fixed data-2
87 to 91 Fixed data-1 (Initialized data)
92 Fixed data-2
93 to BF Fixed data-1 (Initialized data)
