Spectracom SecureSync 1200 User Manual

Function Name used in Web UI Illustration ID* Inputs Outputs Conn.'s
Quad 1PPS out
(RS-485)
1PPS Out, RS-485
21
0 1PPS, RS-485
(4x)
Terminal
block,
10-pin
Quad 1PPS out
(fiber optic)
1PPS Out, Fiber
2B
0 1PPS, F/O (4x) ST Fiber
optic
(4x)
1in/3out 1PPS
(TTL [BNC])
1PPS/Frequency RS-
485
28
1PPS
(1x)
1PPS (3x) BNC
(4x)
1in/2out
1PPS/freq
(fiber optic)
1PPS In/Out, Fiber
2A
1PPS
(1x)
1PPS (2) ST Fiber
optic
(3x)
5MHz out 5MHz Out
08
0 5MHz (3x) BNC
(3x)
10 MHz out 10 MHz Out
1C
0 10 MHz (3x) BNC
(3x)
10 MHz out 10 MHz Out
38
0 10 MHz (3x) TNC
(3x)
1MHz out 1MHz Out
26
0 1MHz (3x) BNC
(3x)
Progr. frequ.
out (Sine
Wave)
Prog Freq Out, Sine
13
0 progr. clock,
sine (4x)
BNC
(4x)
Progr. frequ out
(TTL)
Prog Freq Out, TTL
2F
0 progr. clock,
TTL/sq. (4x)
BNC
(4x)
Prog frequ out
(RS-485)
Prog Freq Out, RS-485
30
0 progr. clock, RS-
485 (4x)
Terminal
block,
10-pin
Square Wave
out
Square Wave Out,
BNC
17
0 square wave, TTL
(4x)
BNC
(4x)
1PPS in/out +
frequ. in
1PPS/Frequency BNC
01
Var.
frequ.
+
1PPS
1PPS (TTL) BNC
(3x)
1PPS in/out +
frequ. in
1PPS/Frequency RS-
485
03
10
MHz
+
1PPS
1PPS Terminal
block,
10-pin
CTCSS, Data
Sync/Clock
Simulcast
14
0 data clock,
CTCSS frequ.,
1PPS, 1alarm
(3x)
RJ-12 &
DB-9
Telecom Timing Cards
1.5 Option Cards
CHAPTER 1 • SecureSync User Reference Guide Rev. 23
11
