Spectracom SecureSync 1200 User Manual

Function Name used in Web UI Illustration ID* Inputs Outputs Conn.'s
E1/T1 data,
75Ω
E1/T1 Out BNC
09
0 1.544/2.048
MHz (1x) unbal.
E1/T1 (2x)
BNC
(3x)
E1/T1 data,
100/120Ω
E1/T1 Out Terminal
0A
0 1.544/2.048
MHz (1x) unbal.
E1/T1 (2x)
Terminal
block,
10-pin
Time Code Cards
ASCII Time
Code RS-232
ASCII Timecode RS-
232
02
1 RS-232 (1x) DB-9
(2x)
ASCII Time
Code RS-485
ASCII Timecode RS-
485
04
1 1 Terminal
block,
10-pin
IRIG BNC IRIG In/Out BNC
05
1 2 BNC
(3x)
IRIG Fiber
Optic
IRIG In/Out, Fiber
27
1 2 ST Fiber
optic
(3x)
IRIG out, BNC IRIGOut BNC
15
0 4 BNC
(4x)
IRIG out, fiber
optic
IRIG Out, Fiber
1E
0 4 ST Fiber
optic
(4x)
IRIG out, RS-
485
IRIGOut, RS-485
22
0 4 Terminal
block,
10-pin
STANAG input STANAG In
1D
2x 1x DB-25
(1x)
STANAG in,
isol.
STANAG In, Isolated
24
2x 1x DB-25
(1x)
STANAG out STANAG Out
11
0 2x STANAG, 1x
1PPS
DB-25
(1x)
STANAG out,
isol.
STANAG Out, Isolated
25
0 2x STANAG, 1x
1PPS
DB-25
(1x)
HAVE QUICK
out BNC
HAVE QUICK Out,
BNC
10
0 4 (TTL) BNC
(4x)
HAVE QUICK
out RS-485
HAVE QUICK Out, RS-
485
1B
0 4 Terminal
block,
10-pin
HAVE QUICK HAVE QUICK
29
1 3 BNC
(4x)
12
CHAPTER 1 • SecureSync User Reference Guide Rev. 23
1.5 Option Cards
