Programmable Phase Shift: ±5ns to 500ms with 5ns resolution
Maximum Number of Cards: 6
Ordering Information: 1204-28: 1PPS 1-input/3-output, BNC connectors
Figure 5-19: Model 1204-28 option card rear plate
Model 1204-2A 1PPS Input/Output: Specifications
Inputs/Outputs: (1) 1PPS input/(2) 1PPS output
Operating Wavelength: 820/850nm
Optical Input Minimum Sensitivity: -25dBm @ 820nanometers
Optical Output Power: -15 dBm average into 50/125 fiber
Fiber Optic Compatibility: 50/125μm, 62.5/125μm multi-mode cable
Optical Connector: ST
Output Programmable Pulse Width: 100ns to 900ms with 20ns resolution
Output Absolute Phase Error: ±50ns (1σ)
Output Programmable Phase Shift: ±5ns to 500ms with 5ns resolution
Maximum Number of Cards: 6
Ordering Information: 1204-2A: 1PPS 1-in/2-output, ST connectors
Figure 5-20: Model 1204-2A option card rear plate
