Output Port: Pin Assignments
Table 5-25:
Output connector DB-9: pin-out
Pin Number Signal Name Function
Top row of 5 pins
1 NC No Connection
2 SERIAL_OUT_TX RS-232 Transmit data
3 SERIAL_OUT_RX RS-232 Receive data
4 NC No connection
5
GND Ground
Bottom row of 4 pins
6 NC No connection
7 NC No connection
8 NC No connection
9 NC No connection
Viewing the State of Event Broadcast and Event Input
To view the Status of Event Broadcast and Event Input, see "Viewing an Input/Output Signal
State" on page331.
Event Broadcast Output: Edit Window
To configure the Event Broadcast Output, go to its Edit window. For instructions, see: "Con
figuring Option Card Inputs/Outputs" on page330.
The Web UI list entry for this card is: Event Broadcast.
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out
puts start at1, because of the built-in outputs).
