Manufacturer/Model: The manufacturer and/or model of the GNSS receiver in your Ver-
saSync unit.
Validity: Status indicator lights for TIME and 1PPS signals: “On” (green) indicates a valid
signal, “Off” (red) indicates that no valid signal is available. A yellow 1PPS light indic-
ates that the monitored 1PPS value fell below a quality threshold and the unit is in fly-
wheel mode.
Receiver Mode:
Single Satellite: Used in areas with poor GNSS reception.
Standard:Default operating mode for the GNSS receiver.
Mobile: [default] For non-stationary applications.
Receiver Dynamics: (u-blox receivers only); see "Setting GNSS Receiver Dynamics" on
page155.
Survey Progress: Real-time status:
ACQUIRING (x Satellites)—red
SURVEYING (x %)—yellow; remains at 1% if no satellites are in view
COMPLETE—green
Number of Tracked Satellites: The number of satellites currently being tracked.
Offset: As set by the user, in nanoseconds.
Antenna Sense:
OK (green)
Open: Check the antenna for the presence of an open.
Short: Check the antenna for the presence of a short circuit.
Position: VersaSync’s geographic position by:
Latitude: In degrees, minutes, seconds
Longitude: In degrees, minutes, seconds
Altitude: In meters MSL (Mean Sea Level)
Receiver Constellation: GPS/GLONASS/Galileo/BeiDou/QZSS
Client A-GPS Status: A-GPS is ENABLED and running, or DISABLED
Client A-GPS Data: External A-GPS data is AVAILABLE, or UNAVAILABLE
Server A-GNSS Status: The Rinex Server feature is ENABLED and running, or DISABLED
Server A-GNSS Data: A-GPS data is AVAILABLE and can be downloaded by clients, or it
is UNAVAILABLE
Identified Satellite Signal Strengths: Bar graphs for all satellites detected. Color indicates
signal strength.
150
CHAPTER 3 • VersaSync User Manual Rev. 6.0
3.3 Managing References
