JetStream Specifications
Print Technology
Continuous Inkjet (CIJ)
Nozzle Size
60 µm nozzle standard
Print Speed
Up to 1000′/min (304.8 m/min)
Character Height
0.10" – 0.50" (2.5 mm – 12.7 mm)
Up to 32-dot high font with single line of text
Throw Distance
Up to 1.2" (30 mm) distance from Printhead to substrate
Message Storage
8 GB
Communication Inputs
Photocell/Trigger, Encoder, Reverse Print, BCD Select, RS232, Reset
Counter
Outputs
Alarm Red/Yellow/Green (discreet)
Communication Ports
I/O, RS232. Sensor, Encoder, USB, Ethernet
Product Sensor
NPN photocell sensor
Printhead Dimensions
Diameter: 1.77" (45 mm)
Length: 9.25" (235 mm)
Umbilical Tube Length
Vinyl-covered armored conduit
118.11" (3 m) standard
Console Construction
Stainless steel
Console Dimensions
Height: 19.3" (490 mm)
Width: 14.57" (370 mm)
Depth: 12.1" (307 mm)
Electrical Requirements
90–240 VAC, 50/60 Hz
Properly wired and grounded
Operating Environment
41° F – 113° F (5° C – 45° C)
Humidity Range
30%–95% relative humidity, non-condensing
Altitude Range
Within 1000 meters above sea level
Weight
53 lbs (24 kg)
Inks
Comprehensive range including MEK, Acetone, and Ethanol-based
