Squid Ink JetStream - JetStream System Components; Console Component Overview

System Components 33
2006792 Rev B – 200228
System Components
The JetStream consists of a Console, Umbilical Tube, and Printhead. The Umbilical Tube
contains wires and ink tubes that convey information and fluids back and forth between the
Console and the Printhead.
Console Overview
Electronics Compartment
The Electronics Compartment is located behind the Touchscreen, and is beyond the scope
of this User Guide.
CAUTION – PROPERTY DAMAGE: Do not attempt to repair or modify any
electronics yourself. Doing so can damage the system and void the warranty.
For issues with the electronics of the JetStream, contact your authorized and
qualified Squid Ink Distributor.
LCD Touchscreen
Electronics
Compartment
Ink
Compartment
Power Switch and
Power Input
Rear
Compartment
Front View
Rear View
