Squid Ink JetStream - Configure Print Speed and Direction

Installation and Setup 65
2006792 Rev B – 200228
Determining the Correct Print Speed and Direction
Finding the ideal combination of conveyor speed and print speed should be performed a
qualified technician during setup, and will usually involve some trial and error.
CAUTION – PROPERTY DAMAGE: This function should not be performed by
unauthorized personnel. If in doubt, contact your authorized Squid ink Distributor.
A good starting point is the print speed chart below. All data in the chart assumes that the
JetStream is running in High Speed print mode (see “Charging Mode” on page 99):
Raster Mode
Maximum Speed
Dimensions
Number of Lines
Feet per minute
Meters per minute
5x5
A (1 line)
950
290
B (2 lines)
375
114
C (3 lines)
180
55
D (4 lines)
90
27
7x5
A (1 line)
625
190
B (2 lines)
275
84
C (3 lines)
125
38
D (4 lines)
75
23
9x7
A (1 line)
400
122
B (2 lines)
120
37
12x10
A (1 line)
240
73
B (2 lines)
110
34
16x12
A (1 line)
180
55
B (2 lines)
75
23
24x18
A (1 line)
100
30
32x24
A (1 line)
75
23
