46 Installation and Setup
2006792 Rev B – 200228
2. Attach the rear Reinforcement Bracket
a. Use the M6-12 Screws to attach the rear reinforcement bracket to the back legs of
the Stand.
b. Use the M-6 Nuts and M-6 Lock Washers to secure the screws in place.
NOTE: Adding the rear reinforcement bracket will result in the back door of the
lower JetStream being inaccessible. However, any maintenance that requires
opening the rear door of the JetStream should be performed by an authorized
service technician.
