Customer Replaceable Units Right and Left Side Panels
Page 163
© Copyright 2020 Stratasys. All rights reserved.
6. Press and hold down the side panel retaining slot on the cover support bracket. See
Figure 18 (page 163).
Figure 18: Side Panel Mounting Screw Locations (right side panel shown)
Side Panel
Retaining Slot
Side Panel
Mounting Screws
