Objet1000 Plus User Guide 6 Operating and Maintaining the Objet1000 Plus 3DPrinter
DOC-06810 Rev.B 6-38
9. Foreachcolumnoflines,useamagnifyingglassorloupetoinspectpairs
ofconsecutiverowsprintedonthetransparencytoseewherethevertical
linesalign.
Figure6-46Comparingrowsofalignmentlines
Note: Itdoesnotmatterwhichpairoflinesyouinspect,sincetheywereall
printedbythesamehead.Chooseapairofclearlyprintedlinesforthe
inspection.(Sincesomenozzlesmaynotprintclearly,youmayhaveto
inspectseveralpairsoflinestoproperlyviewthealignment.)
Optimumheadalignmentisshownwhenthefourthlinesintheupperand
lowerrowsarealigned,Figure6-46.Intheexampleshown,nochangeto
theheadalignmentisnecessary.Ifotherlinesinthesetarealigned,you
needtochangethealignmentofthathead—inthenextwizardscreens.
10.InthewizardscreenshowninFigure6-44,selecttheTransparency
removedcheckbox,andclickNext.
Thefirstinaseriesofalignmentscreensappears.
Figure6-47Headalignmentselection
11.Inthehead-alignmentscreen,selectthenumberthatindicateswhich
linesalignintheupperandlowerrowsofapaironthetransparency
(countingfromtheleft)forthisprinthead.
Note: Becausethealignmentofthefourthlinesisoptimum,thenumber“4”
isselected,bydefault,inthewizardscreen.Thisdoesnotchangethehead
alignment.Ifyouselectothernumbers,thewizardadjuststhehead
alignment,accordingly.
12.ClickNexttodisplaythenextheadalignmentscreen,andagainselectthe
numberrepresentingthemostcloselyalignedverticallinesonthe
transparencyforthatprinthead.
