Operating the Equipment Locally
Page 4-50 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
FIELD 1 FIELD 2
7 Teletext System B or Inverted Teletext, VITC, Video Index,
Closed Caption, Wide Screen Signalling (WSS), Off, Video
Programming System (VPS)
319 Same options as line 7
8 Same options as line 7 320 Same options as line 7
9 Same options as line 7 321 Same options as line 7
10 Same options as line 7 322 Same options as line 7
11 Same options as line 7 323 Same options as line 7
12 Same options as line 7 324 Same options as line 7
13 Same options as line 7 325 Same options as line 7
14 Same options as line 7 326 Same options as line 7
15 Same options as line 7 327 Same options as line 7
16 Same options as line 7 328 Same options as line 7
17 Same options as line 7 329 Same options as line 7
18 Same options as line 7 330 Same options as line 7
19 Same options as line 7 331 Same options as line 7
20 Same options as line 7 332 Same options as line 7
21 Same options as line 7 333 Same options as line 7
22 Same options as line 7 334 Same options as line 7
23 Same options as line 7 Start of coded video. 335 Same options as line 7
24 Same options as line 7 ACTIVE VIDEO 336 Same options as line 7 Start of coded video.
25 -
310
ACTIVE VIDEO 337 -
622
ACTIVE VIDEO
311 -
312
Equalising Pulses 623 ACTIVE VIDEO / Equalising Pulses
313 Equalising Pulses (part) 624 -
625
Equalising Pulses
NOTES…
1. Any type of valid VBI can be on any line, even if it is not usually associated with that line.
2. 625-line fields start on the leading edge of the first vertical sync (broad) pulse. Therefore, the first
half of line 313 is in field 1 and the second half is in field 2.
3. An MPEG frame is 576 lines when formatting 625-line format pictures.
4. Line 23 is the Wide Screen Signalling line. It carries information which defines the picture Aspect
Ratio.
5. ETS 300 294 is the specification which describes WSS.
6. EN 300 472 is the specification associated with System B Teletext (World System Teletext).
Figure 4.13: VBI Structure Implemented by TANDBERG for 625-line Systems
