Operating the Equipment Locally
Page 4-76 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
FEC (HP)
FEC (HP) : +
1/2 —
Enter l
Update using softkeys Quit l
The screen for the FEC (LP) option is the same except that (LP) replaces
(HP).
Table 4.69: FEC (HP) and FEC (LP) Options
Selected Option Description
1/2 Terrestrial transmitter FEC rate HP/LP is 1/2.
2/3 Terrestrial transmitter FEC rate HP/LP is 2/3.
3/4 Terrestrial transmitter FEC rate HP/LP is 3/4.
5/6 Terrestrial transmitter FEC rate HP/LP is 5/6.
7/8 Terrestrial transmitter FEC rate HP/LP is 7/8.
Guard Interval Option
To access the Guard Interval option, press the Guard Interval softkey in
the Delivery Descriptor Menu. This enables the guard interval of the
terrestrial transmitter to be specified.
Guard Interval
Guard Interval : +
1/32 —
Enter l
Update using softkeys Quit l
Table 4.70: Guard Interval Options
Selected Option Description
1/4 Terrestrial transmitter guard interval is 1/4.
1/8 Terrestrial transmitter guard interval is 1/8.
1/16 Terrestrial transmitter guard interval is 1/16.
1/32 Terrestrial transmitter guard interval is 1/32.
Carriers Options
To access the Carriers option, press the Carriers softkey in the Delivery
Descriptor Menu. This enables the transmission mode (i.e. number of
carriers in an OFDM frame) used by the terrestrial transmitter to be
specified.
