Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-69
ST.TM.E10074.1
SNMP oid index
¬ Left SNMP oid index : +
® Right `2’ —
l Ins Enter l
l Del Update using softkeys Quit l
Table 4.60: SNMP oid index Options
Selected Option Description
Min: 1
Max: 7
Oid index
Version Option
This option indicates the version of the data. It is for status only and
cannot be changed.
4.10.3 Data XA - RS232 Menu (When M2/EOM2/DAT Fitted)
Encoding Option
To access the Encoding option, press the Encoding softkey in the
Data XA - RS232 Menu (X = the number of the option slot that the
module is fitted into). This enables the RS-232 asynchronous data channel
to be switched On or Off.
Baud Rate Option
To access the Baud Rate option, press the Baud Rate softkey in the
Data XA - RS232 Menu. This enables the baud rate of the RS-232
asynchronous data channel to be set.
Baud Rate
RS232 Data Baud Rate : +
38400 —
Enter l
Update using softkeys Quit l
Table 4.61: Baud Rate Options
Selected Option Description Selected Option Description
1200 1200 Baud rate. 9600 9600 Baud rate.
2400 2400 Baud rate. 19200 19200 Baud rate.
4800 4800 Baud rate. 38400 38400 Baud rate.
