Technical Specification
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page B-3
ST.TM.E10074.1
B.1 Inputs
B.1.1 Video
SDI
Table B.1: Serial Digital Video Specification
Item Specification
Safety status SELV
Connector designation
SDI IN
Connector type
75 W BNC female socket
Input standard (UK/EC)
Input standard (USA)
ITU-R RECMN BT.656-3 Interfaces for Digital Component Video Signals in
525-Line and 625-Line Television Systems Operating at the 4:2:2 Level of
Recommendation ITU-R BT.601 (Part A).
ANSI / SMPTE 259M Television 10-Bit 4:2:2 Component and 4 fsc
Composite Digital Signals -Serial Digital Interface.
(Encoder only supports Component).
Level C - 270 Mbit/s, 525/625 component.
Cable length 250 m, maximum
Recommended cable type PSF 1/3
Input level 800 mV pk-pk nominal ±10%
Return loss Better than 15 dB, 10 MHz - 270 MHz
Input impedance 75 W (powered-down impedance = 75 W)
H SYNC
Table B.2: H SYNC Specification
Item Specification
Safety status SELV
Connector designation
H SYNC
Connector type
75 W BNC female socket
Input standard 625 line PAL, 525 line PAL-M or 525 line NTSC, chrominance not required.
Input level 1 V pk-pk nominal ±5%
Cable length 250 m, maximum
Return loss Better than 30 dB up to 6 MHz
Input impedance 75 W (powered-down impedance = 75 W)
