TANDBERG evolution 5000 E5710 - Physical Details; Power Supply

Technical Specification
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page B-11
ST.TM.E10074.1
B.5 Power Supply
This equipment is fitted with an auto-ranging power supply. It is suitable
for supply voltages of 100-120 Vac -10% +6% or 220-240 Vac -10% +6%
at 50/60 Hz nominal.
Table B.17: AC Power Supply Specification
Item Specification
Power distribution system Type TN ONLY (EN 60950 para 1.2.12.1): Power distribution system having one point
directly earthed, the exposed conductive parts of the installation being connected to
that point by protective earth conductors. This equipment must NOT be used with
single-phase three-wire and PE, TT or IT Type Power distribution systems.
Connection to supply Pluggable Equipment Type A (EN 60950 para 1.2.5): Equipment which is intended for
connection to the building power supply wiring via a non-industrial plug and
socket-outlet or a non-industrial appliance coupler or both. Correct mains polarity
must always be observed. Do not use reversible plugs with this equipment.
Class of equipment Class I Equipment (EN 60950 para 1.2.4): electric shock protection by basic
insulation and protective earth.
Rated voltage 100-120/220-240 Vac (single phase)
Rated frequency 50/60 Hz
Voltage selection Auto-ranging
Rated current 1U
2U
2 A (100-120 Vac range)
1 A (220-240 Vac range)
4 A (100-120 Vac range)
2 A (220-240 Vac range)
Input connector CEE 22/IEC 3-pin male receptacle
Fuse Fuse in live conductor in power input filter at rear of unit. Do not use reversible plugs
with this equipment.
Fuse type 5 x 20 mm IEC127 Sheet V e.g.:
Bussmann S505 series
Littelfuse 215 series
Fuse current rating 5 A 250 V T HBC
Power consumption 1U
2U
150 W maximum
250 W maximum
Stand-by power 1U
2U
6 W typically
15 W typically
B.6 Physical Details
Table B.18: Physical Details
Item Specification
Height 1U, 44.5 mm chassis
2U, 88.9 mm chassis
Width 1U, 442.5 mm excluding fixing brackets
2U, 442.5 mm excluding fixing brackets
Overall width 1U, 482.6 mm including fixing brackets
2U, 482.6 mm including fixing brackets
Depth 1U, 545 mm excluding rear connector clearance
2U, 545 mm excluding rear connector clearance
Approximate weight 1U, 7.5 kg (16.5 lbs)
2U, 11.5 kg (25.3 lbs)
