B.10.3 M2/EOM2/REMUX Remux Option Module
Connectors
NOTE…
The M2/EOM2/REMUX Remux Option Module is supported by Encoder software version 2.2 and later.
Table B.23: DVB ASI In 1, 2 and 3 Connector
Item Specification
Safety status SELV
Connector designation DVB ASI IN 1, DVB ASI IN 2, DVB ASI IN 3
Connector type BNC
Connector impedance 75 W
4
Data coding 8B/10B
Channel rate 270 Mbit/s
Specification DVB A010 rev 1 (Asynchronous Serial Interface)
5
Table B.24: DVB ASI Out 1 Connector (Disabled)
Item Specification
Safety status SELV
Connector designation DVB ASI OUT 1
Connector type BNC
Connector impedance 75 W
6
Data coding 8B/10B
Channel rate 270 Mbit/s
Specification DVB A010 rev 1 (Asynchronous Serial Interface)
7
LEDs
Table B.25: DVB ASI In 1, 2 and 3 - LED Indications
Item Specification
Red LED Input ASI lock
On No lock on ASI (8B/10B coding)
Off Input ASI lock OK
Green LED Packet size
Off Not locked to MPEG packets
Flash (1:3 mark:space) 188 byte packets
Flash (3:1 mark:space) 204 byte packets
4
75 W terminator must be fitted when this interface is not in use.
5
Byte mode and single packet burst mode only.
6
75 W terminator must be fitted when this interface is not in use.
7
Byte mode and single packet burst mode only.
