4.11.2 Output Format Option
To access the Output Format option, press the Output Format softkey in
the Output Menu. The output format of the Encoder cannot be changed and
is set to ASI.
4.11.3 Delivery Descriptor Menu
To access the Delivery Descriptor Menu, press the Delivery
Descriptor softkey in the Output Menu. The screens in this menu vary
according to the Descriptor Type selected.
4.11.4 Descriptor Type Option
To access the Descriptor Type option, press the Descriptor Type softkey
in the Delivery Descriptor Menu. This enables the descriptor type to be
specified.
Descriptor Type
Descriptor Type : +
Terrestrial —
Enter l
Update using softkeys Quit l
Table 4.62: Descriptor Type Options
Selected Option Description Comments
Satellite Descriptor type set to Satellite.
Terrestrial Descriptor type set to Terrestrial.
None
Cable Descriptor type set to Cable.
The type of delivery descriptor
selected affects the remaining
options shown on the Delivery
Descriptor Menu.
4.11.5 Descriptor Type = Terrestrial
Band Plan Option
To access the Band Plan option, press the Band Plan softkey in the
Delivery Descriptor Menu.
Once a country has been selected then the required channel should be
selected in the Channel option. Each channel number corresponds to a
particular frequency (see Annex F, Band Plans).
Band Plan
Band Plan : +
Australia —
Enter l
Update using softkeys Quit l
