TANDBERG evolution 5000 E5710 - Sabus Baud Rate Option; Serial Protocol Option

Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-23
ST.TM.E10074.1
SABus Address
¬ Left SABus Address : +
® Right `49’ —
l Ins Enter l
l Del Update using softkeys Quit l
Table 4.10: SABus Address Options
Selected Option Description
Min: 49
Max: 127
Step Size: 1
SAbus address.
Serial Protocol Option
To access the Serial Protocol option press the Serial Protocol softkey in
the Remote Control Menu. This option enables the type of serial protocol
to be set.
Serial Protocol
Serial Protocol : +
RS485 —
Enter l
Update using softkeys Quit l
Table 4.11: Serial Protocol Options
Selected Option Description
RS485 The type of serial protocol used.
RS232 The type of serial protocol used.
SABus Baud Rate Option
To access the SABus Baud Rate option, press the SABus Baud Rate
softkey in the Remote Control Menu.
SABus Baud Rate
SABus Baud Rate : +
19200 —
Enter l
Update using softkeys Quit l
Table 4.12: SABus Baud Rate Options
Selected Option Description Selected Option Description
1200 1200 Baud rate. 9600 9600 Baud rate.
2400 2400 Baud rate. 19200 19200 Baud rate.
4800 4800 Baud rate. 38400 38400 Baud rate.
