Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-77
ST.TM.E10074.1
Carriers
Carriers : +
2k Mode —
Enter l
Update using softkeys Quit l
Table 4.71: Carriers Options
Selected Option Description
2k Mode Terrestrial transmitter uses 2k transmission mode
(2k carriers in an OFDM frame).
8k Mode Terrestrial transmitter uses 8k transmission mode
(8k carriers in an OFDM frame).
Other Frequency Option
To access the Other Frequency option, press the Other Frequency
softkey in the Delivery Descriptor Menu. This enables the flag which
specifies whether other frequencies are in use or not to be set.
Other Frequency
Other Frequency : +
In Use —
Enter l
Update using softkeys Quit l
Table 4.72: Other Frequency Options
Selected Option Description
None No other frequency is in use.
in use One or more other frequencies are in use.
4.11.6 Descriptor Type = Cable
Frequency Option
See Frequency Option on page 4-73.
Modulation Type Option
To access the Modulation Type option, press the Modulation Type softkey
in the Delivery Descriptor Menu. This screen enables the type of
modulation used by the cable channel to be specified.
Modulation Type
Modulation Type : +
QPSK —
Enter l
Update using softkeys Quit l
