Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-73
ST.TM.E10074.1
Table 4.63: Band Plan Options
Selected Option Selected Option
Australia Ireland
Europe VHF South Africa
Europe CATV French Overseas PIA
Italy France
Morocco Japan
New Zealand USA
China CCIR
8
OIRT
9
Manual
Channel Option
To access the Channel option, press the Channel softkey in the Delivery
Descriptor Menu. Each channel number corresponds to a particular
frequency (see Annex F, Band Plans).
Channel
Channel : +
2—
Enter l
Update using softkeys Quit l
Table 4.64: Channel Options
Valid Input Range Description
Depends upon the country
selected.
See Annex F, Band Plans for the frequencies
associated with particular countries.
Frequency Option
To access the Frequency option, press the Frequency softkey in the
Delivery Descriptor Menu. This enables the carrier frequency of the
transmitter to be specified.
NOTES…
1. This option is not displayed if the unit is set to generate PSIP externally or it is under MEM
control.
2. This option is status only unless Manual has been selected in the Band Plan option.
8
CCIR is now know as International Telecommunications Union-Radiocommunications Study Groups.
9
Organisation that co-ordinated TV standards and programme interchange among the Eastern–block countries of
Europe.
