Technical Specification
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page B-15
ST.TM.E10074.1
B.10 Option Modules
B.10.1 M2/EOM2/AUDLIN Additional Audio and Linear PCM
Option Module
See Section B.1.2, Audio for details.
B.10.2 M2/EOM2/DAT RS-232 and RS-422 Data Input
Option
Asynchronous Data Input
A 9-way, D-type female connector provides an RS-232 asynchronous,
serial communications data input interface.
Table B.21: RS-232 Asynchronous Data Input Specification
Item Specification
Safety status SELV
Type ITU-T V.24/V.28 (RS-232D) asynchronous serial data
Connector designation ASYNC
Connector type 9-way D-type female
Supported baud rates 1200, 2400, 4800, 9600, 19200, 38400 baud
Control mechanism XON/XOFF
Time-stamp Not supported
Synchronous Data Input
A 15-way, D-type female connector provides an RS-422 synchronous,
serial communications data input interface.
Table B.22: RS-422 Synchronous Data Input Specification
Item Specification
Safety status SELV
Type ITU-T V.11 (RS-422), synchronous serial data and external clock
Connector designation SYNC
Connector type 15-way D-type female
Clock frequencies n x 64 kbit/s from 64 kbit/s to 2048 kbit/s (selectable)
or
n x 56 kbit/s from 56 kbit/s to 1792 kbit/s (selectable)
Time-stamp Not supported
Operation modes Bit-pipe - Transport packet alignment and byte alignment relative
to the incoming bit-stream are arbitrary.
