Operating the Equipment Locally
Page 4-80 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Symbol Rate
See Symbol Rate Option on page 4-79.
Orbital Position Option
To access the Orbital Position option, press the Orbital Position softkey in
the Delivery Descriptor Menu.
This enables the orbital position of the satellite to be specified.
Orbital Position
¬ Left Orbital Position : +
® Right `36.8°’ —
l Ins Enter l
l Del Update using softkeys Quit l
Table 4.78: Orbital Position Options
Valid Input Range Description
Min: 0.0°
Max: 360.0°
Step Size: 0.1°
If the specified orbital position is outside the valid input range, a
confirmation screen is displayed which shows the maximum/minimum
value allowed.
West East Option
To access the West East option, press the West East softkey in the
Delivery Descriptor Menu.
This enables the satellite west/east flag to be specified to indicate whether
the satellite position is in the western or eastern part of the orbit.
West East
West East : +
West —
Enter l
Update using softkeys Quit l
Table 4.79: West East Options
Selected Option Description
West Satellite position is in western part of the orbit.
East Satellite position is in the eastern part of the orbit.
