TANDBERG evolution 5000 E5710 - 4.11.7 Descriptor Type = Satellite; FEC (Inner) Option; Frequency Option; Modulation Type Option

Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-79
ST.TM.E10074.1
Symbol Rate Option
To access the Symbol Rate option, press the Symbol Rate softkey in the
Delivery Descriptor Menu.
Symbol Rate
¬ Left Symbol Rate : +
® Right `20.0000 Msym/s’ —
l Ins Enter l
l Del Update using softkeys Quit l
Table 4.76: Symbol Rate Options
Valid Input Range Description
Min: 0.4688 Msym/s
Max: 30.0000 Msym/s
Step Size: 0.0001 Msym/s
Symbol rate.
Changing the symbol rate affects the automatic Tx
bandwidth, video bit-rate and video resolution calculations.
4.11.7 Descriptor Type = Satellite
Frequency Option
See Frequency Option on page 4-73.
Modulation Type Option
To access the Modulation Type option, press the Modulation Type softkey
in the Delivery Descriptor Menu. This enables the type of modulation
used by the satellite transponder to be specified.
Modulation Type
Modulation Type : +
QPSK —
Enter l
Update using softkeys Quit l
Table 4.77: Modulation Type Options
Selected Option Description
8PSK Satellite transponder uses 8PSK modulation.
16-QAM Satellite transponder uses 16QAM modulation.
BPSK Satellite transponder uses BPSK modulation.
QPSK Satellite transponder uses QPSK modulation.
FEC (Inner) Option
To access the FEC (Inner) option, press the FEC (Inner) softkey in the
Delivery Descriptor Menu. This screen enables the inner FEC rate used
by the satellite transponder to be specified. See FEC (Inner) Option,
page 4-78 for further details.
