Operating the Equipment Locally
Page 4-58 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Table 4.48: Clip Level Options
Selected Option Description
12 dB 12 dB audio clipping level.
15 dB 15 dB is only available with PCB issue 4 and later (see Build Menu).
18 dB 18 dB audio clipping level.
Impedance Option
To access the Impedance option, press the Impedance softkey in the
Audio A Menu. This screen enables the impedance of the audio input to be
set.
NOTES…
1. This option is only shown when the Coding Standard is MPEG Layer 2, Linear PCM or Dolby
Digital (AC-3).
2. This option is only displayed when the audio source is analogue.
Impedance
Audio Impedance : +
600 ohms —
Enter l
Update using softkeys Quit l
Table 4.49: Impedance Options
Selected Option Description
600 ohms
20 kohms
Used in analogue mode.
Language or Language Left/Right Option
To access the Language option, press the Language softkey in the
Audio A Menu. This enables the language of the audio channel to be set.
To access the Language Left/Right option, press the Language
Left/Right softkey in the Audio A Menu. This enables the language of the
left and right audio channels to be set.
NOTE…
The Language Left/Right option is only shown when Coding Mode is set to Dual Mono.
Language
Audio Language : +
English —
Enter l
Update using softkeys Quit l
