Technical Specification
Page B-6 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
International Television Standards
Table B.7 shows television standards appropriate to the Encoder.
Table B.7: International Television Standards
As indicated in Menus M M B G H I D
Region USA/Japan ----- Europe / Asia ---- UK
Standard NTSC ------------------------------------------- PAL ---------------------------------
Lines / frame 525 525 625 625 625 625 625
Fields / second 60 60 50 50 50 50 50
Interlace 2/1 2/1 2/1 2/1 2/1 2/1 2/1
Frames / second 30 (29.97) 30 (29.97) 25 25 25 25 25
Lines / second 15 750 15 750 15 625 15 625 15 625 15 625 15 625
Aspect ratio 4 / 3 4 / 3 4 / 3 4 / 3 4 / 3 4 / 3 4/3
Video band (MHz) 4.2 4.2 5.0 5.0 5.0 5.5 6
B.1.2 Audio
Analogue and Digital Audio
Table B.8: Analogue and Digital Audio Specification
Item Specification
Safety status SELV
Connector designation AUDIO IN
Connector type 15-way, D-type male connector
Input standard (analogue) Balanced analogue
Clip level 12 dB, 15 dB or 18 dB
(15 dB available with PCB issue 4 and later)
Sampling rate 32/48 kHz (selectable)
Input impedance 600 W or 20 kW (selectable). 20 kW = default
Input standard (digital) AES/EBU digital
Termination 110 W
Sampling rate 32/48 kHz (selectable)
Input rate 32, 44.1, 48 kHz
Output (digital) ref AES/EBU digital
Impedance 75 W
Sampling rate 48 kHz
Coding Standards
Coding standard (1)
Supported coding modes
Supported coded data rate
MPEG-1 Layer 2 (ISO/IEC 13818)
Single Mono, Dual Mono, Joint Stereo, Stereo
32 kbit/s - 384 kbit/s (see Chapter 1, Introduction, Table 1.5)
Coding standard (2)
Supported coding modes
Supported coded data rate
Dolby Digital (AC-3) (ATSC A/52, DVB TR 102 154)
1/0, 2/0
56 k - 640 kbit/s (see Chapter 1, Introduction, Table 1.6)
Coding standard (3) Dolby Digital AC-3 Pass-through (ATSC A/52, DVB TR 102 154) (see Note 1, after Table)
Coding standard (4) Linear PCM/Dolby E Pass-through (SMPTE 302M) (see Note 1, after Table)
