Technical Specification
Page B-10 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Table B.15: Remote Control Specification
Item Specification
Safety status SELV
Connector designation
REMOTE CONTROL
Connector type 9-way D-type male
B.4.5 RS-232 Data (Asynchronous)
RS-232 is not currently supported on the Base Board in Build version 2.0.0
but it is in the option module M2/EOM2/DAT.
B.4.6 RS-422 Data
This provides an RS-422 synchronous, serial communications data input
interface.
Table B.16: RS-422 Data Specification
Item Specification
Safety status SELV
Type ITU-T V.11 (RS-422), synchronous serial data and external clock
Connector designation RS-422 DATA
Connector type 15-way D-type female
Clock frequencies n x 64 kbit/s from 64 kbit/s to 2048 kbit/s (selectable)
or
n x 56 kbit/s from 56 kbit/s to 1792 kbit/s (selectable)
Time-stamp Not supported
Operation modes Bit-pipe - Transport packet alignment and byte alignment relative to the incoming bit-stream
are arbitrary.
