Operating the Equipment Locally
Page 4-62 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Mixing Level
Mixing Level : +
25 dB —
Enter l
Update using softkeys Quit l
Table 4.55: Mixing Level Options
Selected Option Description
0 dB to 31 dB Mixing levels between 0 dB to 31 dB.
Room Type Option
NOTE…
This option is only shown when the Coding Standard is Dolby Digital (AC-3) and the Production Info
parameter is set to On.
To access the Room Type option, press the Room Type softkey in the
Audio A Menu. This parameter indicates the type and calibration of the
mixing room used for the final audio mixing session.
Room Type
Room Type : +
Not Indicated —
Enter l
Update using softkeys Quit l
Table 4.56: Room Type Options
Selected Option Description
Not Indicated
Small, Flat Mon Type and calibration of the mixing room used
Large, X Curve Mon for the final audio mixing session.
Copyright Option
NOTE…
This option is shown when the Coding Standard is Dolby Digital (AC-3) or MPEG Layer 2.
To access the Copyright option, press the Copyright softkey in the
Audio A Menu. This indicates whether the information in the bit-stream is
shown to be protected by copyright. This option can be turned On
(protected) or Off (not protected).
