DVB ASI IN 1, 2 and 3 Connectors
A 75 W BNC connector provides an input to the unit.
Table 3.7: DVB ASI In Connector
Pin Signal
Centre Signal
Screen Ground
NOTE…
When connecting the inputs, always start from DVB ASI IN 1 and work upwards.
DVB ASI OUT 1 Connector
A 75 W BNC connector provides an output from the unit.
Table 3.8: DVB ASI Out Connector
Pin Signal
Centre Signal
Screen Ground
NOTE…
This output is disabled.
3.7 Software Options
3.7.1 M2/ESO2/NR
This purchasable option upgrades the Encoder to include noise reduction
mode. Contact Customer Services for details.
3.7.2 M2/ESO2/PU
This purchasable option upgrades the performance of the Encoder. Contact
Customer Services for details.
3.7.3 M2/ESO2/VBR
This purchasable option upgrades the Encoder to include variable bit-rate.
Contact Customer Services for details.
3.7.4 M2/ESO2/422
This purchasable option upgrades the Encoder to include 4:2:2 video
encoding mode. Contact Customer Services for details.
