Operating the Equipment Locally
Page 4-84 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Table 4.85: PCR PID Options
Selected Option Description
Min: 1
Max: 8190 (1FFEh)
Step Size: 1
4.12.7 FPGA Firmware
This option indicates the version of the FPGA Firmware. It is for status only
and cannot be changed.
4.12.8 RAS Firmware
This option indicates the version of the RAS Firmware. It is for status only
and cannot be changed.
4.12.9 RAS Options Enabled
Scramble Option
To access the Scramble option, press the Scramble softkey in the Mux
Menu. This enables RAS1 security scrambling of the Encoder transmission
to be switched on or off.
Table 4.86: Scramble Options (RAS)
Selected Option Description
RAS1 (SNG Key) Encoder output is scrambled. Scrambling key used is
entered using the SNG Key (RAS1) option.
Off Encoder output is not scrambled.
SNG Key (RAS1) Option
To access the SNG Key (RAS1) option, press the SNG Key (RAS1)
softkey in the Mux Menu. This enables the scrambling key used in SNG Key
scrambling mode to be set (see the Scramble option). The same
scrambling code must be used at the receive end to unscramble the
transmission.
Enter up to seven digits using the keypad, then press the Enter softkey to
accept the scrambling code. If less then seven digits are entered, they are
prefixed with 0’s (zero) to give a seven digit code.
SNG Key (RAS1)
¬ Left SNG Key (RAS1) : +
® Right `0000123’ —
l Ins Enter l
l Del Update using softkeys Quit l
