TANDBERG evolution 5000 E5710 - Bandwidth Option; Modulation Type Option

Operating the Equipment Locally
Page 4-74 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Frequency
¬ Left Frequency : +
® Right `66.000 MHz’ —
l Ins Enter l
l Del Update using softkeys Quit l
Table 4.65: Frequency Options
Selected Option Description
Min: 0.0001 MHz
Max: 42949.6729 MHz
Step Size: 0.0001 MHz
Carrier frequency of transmitter.
Bandwidth Option
To access the Bandwidth option, press the Bandwidth softkey in the
Delivery Descriptor Menu. This enables the channel spacing of the
terrestrial transmitter to be specified.
NOTE…
This option is status only unless Manual has been selected in the Band Plan option.
Bandwidth
Bandwidth :+
7 MHz —
Enter l
Update using softkeys Quit l
Table 4.66: Bandwidth Options
Selected Option Description
6 MHz Terrestrial transmitter channel spacing is 6 MHz.
7 MHz Terrestrial transmitter channel spacing is 7 MHz.
8 MHz Terrestrial transmitter channel spacing is 8 MHz.
10 MHz Terrestrial transmitter channel spacing is 10 MHz.
12 MHz Terrestrial transmitter channel spacing is 12 MHz.
Modulation Type Option
To access the Modulation Type option, press the Modulation Type softkey
in the Delivery Descriptor Menu. This enables the type of modulation
used to be specified.
