Technical Specification
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page B-9
ST.TM.E10074.1
B.3 ASI Out 1, ASI Out 2, ASI Out 3 Outputs
Table B.12: ASI Out Specification
Item Specification
Safety status SELV
Connector type BNC 75 W
Connector designation ASI OUT 1, ASI OUT 2, ASI OUT 3
B.4 Control and Monitoring
B.4.1 Remote Control - Ethernet 1 and 2
Table B.13: Ethernet Specification
Item Specification
Safety status SELV
Connector designation ETHERNET#1 and ETHERNET#2
Connector type 8-way RJ-45 socket, 10BaseT (ISO 882/3)
B.4.2 Local Control
Local control is by means of the front panel keypad and LCD display.
B.4.3 Alarm
Table B.14: Alarm Specification
Item Specification
Safety status SELV
Connector designation ALARM
Connector type 9-way D-type male
Alarm contacts Change-over contacts (5 W in common)
Fail contacts Change-over contacts (5 W in common)
Reset contacts Short pins 9 and 5 (resets the Encoder)
Relay Contact Rating
Maximum switching power 30 W
Maximum switching voltage 110 V
Maximum switching current 1 A
B.4.4 Remote Control
This connector provides an RS-232/RS-485 user interface control port that
allows the unit to be controlled by an external master.
