TANDBERG evolution 5000 E5710 - Embedded Audio (Via SDI; Test Tones

Technical Specification
Page B-8 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Item Specification
A-weighted 70 dB
Unweighted 70 dB
User Levels @ 1 kHz (0 to 50 dB) K
+10 dB ±0.2 dB
-10 dB ±0.2 dB
-20 dB ±0.2 dB
-30 dB ±0.2 dB
-40 dB ±0.3 dB
-50 dB 0 to -2 dB
Phase @ 0 dBs Z
40 Hz ±2°
100 Hz ±2°
315 Hz ±2°
1 kHz ±2°
6.3 kHz ±2°
10 kHz ±2°
15 kHz ±2°
Embedded Audio (Via SDI)
Audio embedded on the serial digital interface can also be extracted. Up to
four stereo pairs of audio can be extracted from the SDI. The Encoder can
extract two DIDs at once, giving four stereo pairs.
Table B.10: Embedded Audio Specification
Item Specification
Serial Digital Interface
Safety status SELV
Connector designation SDI IN
Connector type BNC female connector
Input standard ITU-R RECMN BT.656-3
SMPTE 272M-A
B.2 Test Tones
Table B.11: Test Tones Specification
Item Specification
Level 0 dB at 18 dB clip level
Frequency 1 kHz at 48 kHz sampling frequency
Bit-rate 96 kbit/s
NOTE…
Clip Level refers to the head room above 0 dBu, prior to the audio being clipped.
