Analogue Video Specification
Table B.3: Analogue Video Specification
Item Specification
Analogue input 625 line composite PAL-B, -D, -G, -H, -I
525 line composite NTSC-M, PAL-M as specified in ITU-R report 624-4, Characteristics of
Television Systems (NTSC with and without set-up of 7.5 IRE)
Connector designation COMP VIDEO
Connector type 75 W BNC socket
Input level 1 V pk-pk nominal ±5%
Return loss Better than 30 dB up to 6 MHz (when impedance is set to 75 W)
Input impedance 75 W/High Z switchable (powered-down impedance = 75 W)
NOTE…
The inputs are isolated from the chassis to prevent 50 Hz/60 Hz hum.
Encoder Settings for PAL/NTSC Video Performance Figures
The Encoder settings for the PAL/NTSC video performance figures are
shown in Table B.4.
NOTE…
The PAL and NTSC video performance figures are measured when the Encoder is connected to an
Alteia
plus
Decoder.
Table B.4: Encoder Settings for PAL/NTSC Video Performance Figures
Item Specification
Noise reduction Off
Video bit-rate 8 Mbit/s
Resolution 720 x 576
GOP IP
Profile 422P@ML
Packet length 188
Mux Bit-rate 40 Mbit/s
PAL Video Performance Figures
Table B.5: PAL System Video Performance Figures
Pattern Item Specification
Input return loss 35 dB
VITS Line 17 Bar amplitude ref (bp) 700 mV ± 7 mV
VITS Line 17 Jitter 5 ns pk-pk
VITS Line 17 Luminance bar tilt ±0.2%
VITS Line 17 2T pulse K-rating ±1.0% KF
