TANDBERG evolution 5000 E5710 - Polarisation Option; Mux Menu; 4.12.1 Overview

Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-81
ST.TM.E10074.1
Polarisation Option
To access the Polarisation option, press the Polarisation softkey in the
Delivery Descriptor Menu.
This enables the polarisation of the satellite transponder to be specified.
Polarisation
Polarisation : +
Linear - Horizontal —
Enter l
Update using softkeys Quit l
Table 4.80: Polarisation Options
Selected Option Description
Linear - Horizontal Satellite transponder uses linear horizontal polarisation.
Linear - Vertical Satellite transponder uses linear vertical polarisation.
Circular - Left Satellite transponder uses circular left polarisation.
Circular - Right Satellite transponder uses circular right polarisation.
4.12 Mux Menu
4.12.1 Overview
Table 4.81: Option Modules Fitted and Enabled
Marketing Code Name of Option Hardware/
Software
Fitted Enabled
M2/ESO2/RAS RAS Software — 4
M2/EDCOM2/BISS BISS scrambling Hardware 4 —
NOTE…
Software options are enabled/disabled. Hardware options are fitted/not fitted.
The Mux Menu is selected from the Setup Menu by pressing the Mux
softkey.
This menu permits the selection of Multiplexer output parameters, RAS
scrambling options (if enabled) and BISS scrambling options (if enabled).
