Options and Upgrades
Page 3-10 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Table 3.6: RS-422 Data Connector (Option Module) - Synchronous
Remote (DTE) Data Module RS-422 (DCE)
Signal Name Signal Direction Pin Signal Name
1 Not connected
Transmit Data A 2 Transmit Data A
Data Terminal Ready A 3 Data Terminal Ready A
Received Data A 4 Received Data A
Data Set Ready A 5 Data Set Ready A
Received Clock A 6 Received Clock A
Transmit Clock A 7 Transmit Clock A
Signal Ground 8 Signal Ground
Transmit Data B 9 Transmit Data B
Data Terminal Ready B 10 Data Terminal Ready B
Received Data B 11 Received Data B
Data Set Ready B 12 Data Set Ready B
Received Clock B 13 Received Clock B
Transmit Clock B 14 Transmit Clock B
15 Not connected
NOTE…
Signal names are with respect to a DTE in accordance with the RS-422 specification. A is positive and
B is negative.
