Operating the Equipment Locally
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page 4-31
ST.TM.E10074.1
Video Input
Video Input : +
Serial Digital —
Enter l
Update using softkeys Quit l
Table 4.22: Video Input Options
Video Type Selected Option Description
None Off Video input switched off.
PAL-B/G/H/I PAL-B/G/H/I composite video input on COMP VIDEO connector.
PAL-D PAL-D composite video input on COMP VIDEO connector.
PAL-M PAL-M composite video input on COMP VIDEO connector.
NTSC with Pedestal NTSC-M composite video input (with Pedestal) on COMP VIDEO connector.
Analogue
Composite
NTSC No Pedestal NTSC-M composite video input (with no Pedestal) on COMP VIDEO connector.
Serial Digital Serial digital video input on SDI IN connector.
Bars & Red Colour bars and red internal test pattern.
Black Black internal test pattern.
Moving Pattern Moving internal test pattern.
Ident, Digital
and Internal
Test Pattern
Video
Sources
Ident Video Source which allows the user to superimpose identification text on the
video. Mainly used for test purposes.
